Minelab VANQUISH 540 User Manual

6
CONTENTS
Detector Settings
BACKLIGHT
The VANQUISH 540 has a red backlight for detecting in low‑
light situations� The Backlight is turned off by default at each
start‑up to reduce battery consumption�
Press the Backlight button to turn the backlight on or off� The
Backlight Indicator appears on the display when the backlight
is on�
The Backlight button The Backlight indicator
VOLUME
The Volume control changes the loudness of target signals�
Use the Volume Minus and Plus buttons to adjust the Volume
Level� Each press will decrease/increase the volume by one
level�
The Volume
adjustment buttons
A low tone will sound when the maximum or minimum volume
level is reached�
The Volume Level indicator on the display shows the current
approximate Volume Level� Each bar represents two levels�
The Volume Level indicator showing
maximum volume (levels 9 or 10)

Minelab VANQUISH 540 Specifications

General

Technology	Multi-IQ
Search Modes	Coin, Relic, Jewelry, Custom, All Metal
Discrimination Segments	25
Sensitivity Levels	10
Volume Levels	10
Audio Tones	5
Bluetooth	Yes
Pinpoint Mode	Yes
Weight	1.3 kg
Waterproof	Coil only (up to 1 meter)
Battery Type	4 x AA
Searchcoil	10" x 7" Double-D
Audio Output	Built-in speaker
Display	LCD
Length	76 cm - 145 cm (30" - 57")
Iron Bias	High
