6. UNPACKING
6.1. Unpacking
The equipment ships in a single large cardboard carton measuring 7 x 13 x 13” pictured in the
figure below.
Figure 5: Shipping carton
Within the carton, the RCM unit is protected by pink foam inserts on the top and bottom, left and
right sides, and a pink anti-static bubble bag.
6.2. Package Contents
The box contains 6 items which are listed below in table 2:
Table 2: Package contents
Item Description
Quantity
RCM Series Unit
1
AC/DC-24-3W1 AC/DC 24V power adapter
1
CBL-3W-X AC power cord (7.5 ft.) with local AC mains
plug option
1
USB-CBL-AB-7+ USB cable (6.8 ft.)
1
HT-4-SMA SMA cable connector wrench
1
A: 7”
B: 13”
C: 13”
We’ve included the SMA
connector wrench as a gift
just to make your life easier.
This tool simplifies and
expedites removal and
tightening of cable
connectors in crowded port
configurations.
