INSTALLATION
2.2 SP1
BCGB2
2-1 MACHINE UNLOADING
Before unloading the machine take off all parts placed on it for packing and transport requirements.
Raise the machine by a cran or other lifting means by hooking the slings as shown in fig. 2.
Avoid jerking movements during lifting of the machine.
Make sure that the crane, sling ropes or fork truck are of the same weight or more than that of machine.
Alternatively when the machine is supplied on pallet it can also be lifted by fork truck (fig. 2.2) by inserting the
forks under the base, taking care not to overturn the machine.
2-2 MACHINE POSITIONING
Choose a well lit position at least 500 LUX) suitable for the electric connection as well as the connection to the
dust suction system and compressed air system if pneumatic adjustment (optional) has been requested.
Make sure that there is sufficient space around the machine for servicing.
Make sure that the floor is solid: we recommend a concrete floor.
If it is necessary to level the machine insert the 4 screws M12 T.E under feet (P fig.2.2) then adjust the screws
using a 19 mm wrench. We recommend to set steel plates with damping material between screws and floor.
If machine is required to be fastened to the floor insert the pivots of the 2 brackets (S fig.2.2a supplied in the
accessory bag) into the holes on the machine frame then screw down the proper screws M10.
Before starting work carefully remove the grease from work areas and safety guards using a suitable diluent.
