SP1 1.5
GENERAL
BC_GB1
1.1 INSTRUCTIONS FOR CONTACTING BY MAIL OR PHONE
When writing or telephoning to the dealer or MINI MAX for whatever reason regarding your machine, always
supply the following information:
1) Machine model
2) Serial number
3) Voltage and frequency
4) Purchase date
5) Name of dealer where you have bought the machine
6) Detailed information about the trouble
7) Detailed information concerning the working to be carried out
8) Period of use - Number of working hours
SCM
Divisioe Mini Max Samco
Via Casale, 450
47827 - VILLA VERUCCHIO - ITALIA
Tel.0541-679580-679578 - Fax. 0541-674273
1-2 NOTES FOR THE USER
The handbook desribes all the operations required for normal maintenance of the machine.
Do not carry out any repairs or operations not described in the handbook.
All operations which require the disassembly of machine parts as well as maintenance operations
should only be carried out by authorized technicians.
Please refer to this instruction manual for the correct use of the machine.
Only trained and authorised staff should use and service the machine after having carefully read
this instruction manual.
Safety norms and all general safety regulations should be strictly adhered to.
Keep the handbook for future reference.
NOTES:only use original SCM spares. The manufacturer will not be held responsible for damages caused
by the use of components which are not the original ones.For information concerning the electric system
always specify the data indicated on the metal plate (fig.1.1) located on the inside of the door giving
access to the electric housing.
FORNIT. Company that carried out the electric system
DATA Date of power unit manufacturing
CODICE DISTINTA Number of electric components bill
N. Wiring diagram number
VOLT RETE Mains voltage for machine supply (V)
VOLT AUX Voltage for auxiliary circuits supply (V)
VOLT FRENO Voltage for motor brake supply (V)
Hz Frequency (Hz)
kW Absorbed power
MACCH. Machine type
