CONTROLS
3.2 SP1
SP1-I3
3-1 CONTROL BOARD
The control board elements are the following ones:
A) Padlockable main switch
B) Luminous selector to lock/release cutterblock brake
D) Manual zero-star-delta starter
E) Emergency pushbutton
F) Fuses
G) Emergency pushbutton outfeed
H) Luminous button for vertical micro adjustment of worktable/spy light showing table locked in position
L) Selector raising and lowering of thicknessing table
M) Speed change lever
3-2 START/STOP OF MACHINE
To start the machine proceed as follows;
1- Make sure that the top hood (Z fig.3.3) is closed
2- Make sure that the emergency button is released, otherwise turn it in the direction of the arrow
3- Make sure that brake is released, selector (B) turned to
4- Turn starter (D) from 0 position to to start position, after 8 seconds turn it to delta position
To stop the cutterblock motor:
Turn starter (D) to 0
It is forbidden to stop the motor by turning selector (B) to
EMERGENCY BUTTONS
In case of danger if you press the emergency button, any function of the machine is locked.
Periodically press the emergency buttons to check whether they are efficient.
3-3 ACCESS TO THE ELECTRIC HOUSING
Access to the electric housing is only allowed to a qualified electrican after having turned the main switch to 0
(A fig. 3.1) and after having unscrewed screws (V fig. 3.1).
Open the panel which is hinged at the bottom and held by a thin steel cable.
DISCESA PIANO SPESSORE
THICKNESSING TABLE LOWERING
DESCENTE TABLE RABOT
SBLOCCAGGIO ALBERO
CUTTERBLOCK LOOSENING
DEBLOCAGE ARBRE
LÖSEN DER WELLE
DEBLOQUEO EJE
BLOCCAGGIO ALBERO
CUTTERBLOCK LOCKING
BLOCAGE ARBRE
BLOCKIERUNG DER WELLE
BLOQUEO EJE
SOLLEVAMENTO PIANO SPESSORE
THICKNESSING TABLE LIFTING
SOULEVEMENT ARBRE RABOT
