CONTROLS
3.4 SP1
SP1-I3
3-4 AUTO-BRAKE MOTOR
Spindle rotation is carried out by an electric auto-brake motor.
Under normal conditions selector (B) is turned to position
When power is shut off by turning the mains switch to 0, the motor brakes automatically and remains braked
until started up again.
In case of operations such as knife fitting etc. where the cutterblock must freely rotate, turn selector (B) to the
position and the pilot lamp (C) lights up: in this position the cutterblock can not be started
The motor can be started up again only if selector (B ) is turned to .
Note: if you turn selector (B) to when the cutterblock is in operation, the brake immeditely intervenes
Note: the material used for auto-brake motors does not contain any cancerous components.
B
