MAINTENANCE
20.4 SP1
BCGB20
TROUBLE
The thicknessing table does not move
CAUSE WHAT TO DO
The nylon slide blocks are dirty Carefully clean the slide blocks and slideways;
(dust and resin residues), after lifting check the chain.
a few millimeters the red pilot lamp
lights up.
CMR card is faulty Check as indicated in SECTION 18
point 1 or replace the card
TROUBLE
The piece is not fed
CAUSE WHAT TO DO
Feed speed not right Select the right speed (see par.9-1)
The thicknessing table is set to a height Set the thicknessing table to the right height: see
more than the piece thickness THICNESSING TABBLE RAISING.
Rupture of the belt receiving the Apply to Technical Service of the Area dealer.
motion from main motor
Rollers pressure not sufficient Adjust the rollers (see par.9-3)
TROUBLE
The motor is running but the cutterblock stops when it touches the piece.
CAUSE WHAT TO DO
The belts between motor pulley Stretch the belts see: par.9-7
and cutterblock are loose
