Machine Overview
Circuit Breakers
A Main Control Circuit Breaker - 4A
B Brush Motor Circuit Breaker - 30A
C Vacuum Motor Circuit Breaker - 20A
D Drive Motor Circuit Breaker - 20A
The circuit breakers are located at the bottom of the back
panel of the machine.
B
C
A
If any of the functions above are not operating, check if the
circuit breaker buttons have tripped. Press to reset.
D
