18
Machine Overview
Solution Tank Drain Hose
The solution tank may be drained by removing the Solution Tank Drain
Hose (A) from the Hose Barb (B) and routing the hose to a floor drain.
A
B
Solution Level Indicator
The Solution Tank Drain Hose also serves as a water level indicator for
the solution tank. The amount of water remaining in the solution tank
can be seen through the clear drain hose. Level markers molded into
the solution tank are positioned at 1/4, 1/2, 3/4, and full levels.
To Next Page
