16
Machine Overview
Handle Adjustment
The E20 handle was designed with operator comfort in mind. The
angle and horizontal position of the handle can be adjusted to suit
the needs of the operator.
Angle Adjustment
The handle angle can be adjusted without tools by loosening the
Angle Adjustment Knob (A) on each side and rotating the handle
to the desired position. There are 5 angular positions 11.25° apart
for a total of 45° between the minimum and maximum position.
A
