Configuration with the CFG-300 LCD Service Tool
Use the buttons described below for entering messages. These buttons are alternate functions
of bypass switches and are physically located in the same position as described below.
11.3.8 Command Menu/FA-300 Config-->Default Configuration
11.4 2. Config Info (Command-Menu
Command Menu/FA-300 Config/Opt. Zone Label
1.Indicating zone label
|
|
|
4.
[NAC-1 ]->Default
[NAC-4 ]->Default
BYPASS SWITCH TRANSLATION
KEY SEQ 1 2 3 4 KEY SEQ 1 2 3 4
--------------------------------------
Zone-1
0 Q Z Zone-2 1
Zone-3 2 A B C Zone-4 3 D E F
Zone-5 4 G H I Zone-6 5 J K L
Zone-7 6 M N O Zone-8 7 P R S
Zone-9 8 T U V Zone-10 9 W X Y
Zone-11 Back Space Zone-12 Forward
Note: Refer to 11.2.1 Using the Keypad to Program the FA-300 on page 61 for detailed
instructions on making menu selections.
Press the up and down arrow buttons to select
between Y/N. Press ENTER to restore the
default configuration.
Use this menu to load the default configuration in
the panel.
Warning: When you load the default
configuration, the previously programmed
configuration is lost permanently.
Note: Refer to 11.2.1 Using the Keypad to Program the FA-300 on page 61 for detailed
instructions on making menu selections.
NAC-1 Label
NAC-1
NAC-4 Label
NAC-4
i
Load the default
settings? Y
Default settings
have been loaded
i
