Misonix SONICATOR XL2015 - XL2010 & XL2015 Functions

Operation Manual ____________________Function of Controls and Indicators
_________________________________________________________________________________________________
5-3
XL2010 & XL2015 FUNCTIONS
POSITION
NO.
CONTROLS FUNCTION
1. Overload Indicator Indicates a load condition greater than the maximum output
power of the generator or that the unit requires tuning or
other readjustments.
2. Tuning Switch Activates tuning circuit.
3. Power Switch ON Position (I) – energizes generator.
OFF Position (O) – de-energizes generator.
4. Power Output Display Indicates a RELATIVE percentage of maximum available
ultrasonic power delivered to the horn (i.e. 40% output = 0.4
x 550 Watts available = 220 Watts delivered).
5. PULSAR
TM
Cycle Timer
(XL2015 Only)
Activates pulsed energy. Pulse width adjusts from 0.05 of a
second (5% duty) to 0.95 of a second (95% duty) every
second.
6. Amplitude Control Knob Controls the amplitude of ultrasonic vibration at the tip of
the horn.
7. Tuning Control Knob Allows adjustment of generator frequency to optimize
performance of convertor/horn assembly. Also used to
verify condition of horn and/or tip.
8. SHV Cable Connector Connects convertor cable to generator.
9. Footswitch Jack Connects external ON/OFF control (Foot Switch or Timer).
10. Power Receptacle Connects line cord to generator.
11. Fuse (10 amp 115V)
( 8 amp 220V)
Protects against electrical overload.
