Misonix SONICATOR XL2015 - Timer and Pulsar TM Mode

Operation Manual _____________Programming the Microprocessor of XL2020
_________________________________________________________________________________________________
8-4
programming mode. Timer and PULSAR or
(alternates with)
Press START for
Continuous Operation
TIMER AND PULSAR
TM
MODE
Ultrasonic energy is delivered in pulsed cycles (programmable ON and OFF times), for a
specified total processing time. The range of pulse ON and OFF times can be entered from
00:00.1 to 59:59.1 (min:sec.tenths), with a maximum total processing time of 9:59:59
(hr:min:sec).
Programming Steps and Descriptions Action LCD Display
Turn ON generator.
Press “I” on Power
Switch
SONICATOR XL2020
MISONIX INCORPORATED
(Scrolls on screen, then switches to)
For Tuning Procedure
Refer to Manual
(alternates with)
If SONICATOR is Tuned,
Press CLEAR
Clear introduction message.
Press CLEAR Key
Press PROG to Program
Timer and PULSAR or
(alternates with)
Press START for
Continuous Operation
Begin programming. Press PROG. Key
DATA
0:00:00 PROG, START, CLEAR
00:00.0 (MEM.0) 00:00.0
Select the default memory location
(MEM.0)
Press PROG. Key
DATA
0:00:00 (hr:min:sec)
Enter Total Process Time
(alternates with)
0:00:00 (hr:min:sec)
Then Press ENTER
Enter total processing time from
00:00:01 to 9:59:59.
For example: 10 minutes
Press [1] [0] [0]
[0] Keys, and then
press ENTER Key
Enter Pulse ON Time
00:00.0 (min:sec.tenths)
(alternates with)
Then Press ENTER
00:00.0 (min:sec.tenths)
Enter pulse ON time from 00:00:00.1 to
59:59:00.1.
For example: 1 second
Press [1] [0] Keys,
and then press
ENTER Key
Enter Pulse OFF Time
(min:sec.tenths) 00:00.0
(alternates with)
Then Press ENTER
(min:sec.tenths) 00:00.0
Enter pulse OFF time from 00:00:00.1 to
59:59:00.1.
For example: 1.5 seconds
Press [1] [5] Keys,
and then press
ENTER Key
0:10:00 PROG, START, CLEAR
00:01.0 (MEM.0) 00:01.5
Start sonication in timed and pulsed
mode. (Turn Amplitude Control Knob to
desired level)
Press START Key
STOP
0:10:00 Pulsing 0:00:00
(Elapsed Time begins to count seconds)
To interrupt processing. Press PAUSE Key 0:10:00 Pulsing X:XX:XX
Press PAUSE to Continue
To continue processing. Press PAUSE Key 0:10:00 Pulsing X:XX:XX
(Timer continues to count seconds)
To display parameters of program. Press PROG. Key
DATA
0:10:00 hr:mn:sc X:XX:XX
00:01.0 min:sec 00:01.5
(Then switches back to)
