3. SPECIFICATIONS FOR XL2020, XL2015 & XL2010
Generator 110 Vac 220 Vac
Input Voltage 100-130 Vac @ 50/60 Hz 200-260 Vac @ 50/60 Hz
Full Load Current 10 Amps 7.5 Amps
Fuse Rating 10 Amps (GDB10)* 8 Amps (GDB8)*
Weight 14 lbs. (6.3Kg) 16.5 lbs. (7.4Kg)
Dimensions 7.5"x18.5"x11.6" (WxLxH)
19cm x 47cm x 29.5cm
7.5"x18.5"x11.6" (WxLxH)
19cm x 47cm x 29.5cm
Output Voltage 1500 V rms (max.) 1500 V rms (max.)
Output Frequency 20 KHz (nom.) 20 KHz (nom.)
Convertor
Weight 2 lbs. (0.9 Kg) 2 lbs. (0.9 Kg)
Dimensions 8" L x 2.5" Dia.
(20.3cm x 6.4cm)
8" L x 2.5" Dia.
(20.3cm x 6.4cm)
Materials Aluminum Aluminum
Standard Horn
Weight 0.5 lbs. (0.45Kg) 0.5 lbs. (0.45Kg)
Dimensions 5" L x1.5" Dia.
(12.7cm x 3.8cm)
5" L x1.5" Dia.
(12.7cm x 3.8cm)
Materials Titanium Alloy Titanium Alloy
Environmental
Pollution Degree Two (2) Two (2)
Installation Category II II
Temperature Limits 50 F to 110 F
(10 C to 43 C)
50 F to 110 F
(10 C to 43 C)
Barometric Pressure Unlimited** Unlimited**
* Only use IEC approved fuses, model GDB10 for 110V and GDB8 for 220V. Do NOT use “slow
blow” fuses or fuses rated above the amperage noted.
** In a Vacuum area, additional cooling provisions may be needed.
ACCESSORIES
Use only accessories and probes listed in the Misonix catalog as suitable for use with this
equipment. Do NOT attempt to fabricate ultrasonic tooling or accessories unless approval has
been obtained from Misonix in advance.
