Misonix SONICATOR XL2015 - Timer Mode Only

Operation Manual _____________Programming the Microprocessor of XL2020
_________________________________________________________________________________________________
8-2
TIMER MODE ONLY
Ultrasonic energy is delivered continuously for a specified length of time up to 9:59:59
(hr:min:sec).
Programming Steps and Descriptions Action LCD Display
Turn ON generator.
Press “I” on Power
Switch
SONICATOR XL2020
MISONIX INCORPORATED
(Scrolls on screen, then switches to)
For Tuning Procedure
Refer to Manual
(alternates with)
If SONICATOR is Tuned,
Press CLEAR
Clear introduction message.
Press CLEAR Key
Press PROG to Program
Timer and PULSAR or
(alternates with)
Press START for
Continuous Operation
Begin programming. Press PROG. Key
DATA
0:00:00 PROG, START, CLEAR
00:00.0 (MEM.0) 00:00.0
Select the default memory location
(MEM.0)
Press PROG. Key
DATA
0:00:00 (hr:min:sec)
Enter Total Process Time
(alternates with)
0:00:00 (hr:min:sec)
Then Press ENTER
Enter total processing time from
00:00:01 to 9:59:59.
For example: 20 minutes
Press [2] [0] [0]
[0] Keys, and then
press ENTER Key
Enter Pulse ON Time
00:00.0 (min:sec.tenths)
(alternates with)
Then Press ENTER
00:00.0 (min:sec.tenths)
Skip pulsing feature.
Enter 0 for pulse ON time.
Press [0] Key, and
then press ENTER
Key
0:20:00 PROG, START, CLEAR
00:00.0 (MEM.0) 00:00.0
Start sonication in timed mode.
(Turn Amplitude Control Knob to desired
level)
Press START Key
STOP
0:20:00 0:00:00
(Elapsed Time begins to count seconds)
To interrupt processing. Press PAUSE Key 0:20:00 X:XX:XX
Press PAUSE to Continue
To continue processing. Press PAUSE Key 0:20:00 X:XX:XX
(Timer continues to count seconds)
To display parameters of program. Press PROG. Key
DATA
0:20:00 hr:mn:sc X:XX:XX
00:00.0 min:sec 00:00.0
(Then switches back to)
0:20:00 X:XX:XX
(Timer is always counting seconds)
To abort program. Press START Key
STOP
0:20:00 PROG, START, CLEAR
00:00.0 (MEM.0) 00:00.0
When program is completed, exit
programming mode.
Press CLEAR Key Press PROG to Program
Timer and PULSAR or
(alternates with)
Press START for
Continuous Operation
