Misonix SONICATOR XL2015 - Pulsar TM Mode Only

Operation Manual _____________Programming the Microprocessor of XL2020
_________________________________________________________________________________________________
8-4
PULSAR
TM
MODE ONLY
Ultrasonic energy is delivered in pulsed cycles (programmable ON and OFF times), but
without a specified total processing time. The range of pulse ON and OFF times can be
entered from 00:00.1 to 59:59.1 (min:sec.tenths). Ultrasonic output will shut down when the
total processing time reaches 9:59:59 (hr:min:sec).
Programming Steps and Descriptions Action LCD Display
Turn ON generator.
Press “I” on Power
Switch
SONICATOR XL2020
MISONIX INCORPORATED
(Scrolls on screen, then switches to)
For Tuning Procedure
Refer to Manual
(alternates with)
If SONICATOR is Tuned,
Press CLEAR
Clear introduction message.
Press CLEAR Key
Press PROG to Program
Timer and PULSAR or
(alternates with)
Press START for
Continuous Operation
Begin programming. Press PROG. Key
DATA
0:00:00 PROG, START, CLEAR
00:00.0 (MEM.0) 00:00.0
Select the default memory location
(MEM.0)
Press PROG. Key
DATA
0:00:00 (hr:min:sec)
Enter Total Process Time
(alternates with)
0:00:00 (hr:min:sec)
Then Press ENTER
Skip timer feature.
Enter 0 for total process time.
Press [0] Key, and
then press ENTER
Key
Enter Pulse ON Time
00:00.0 (min:sec.tenths)
(alternates with)
Then Press ENTER
00:00.0 (min:sec.tenths)
Enter pulse ON time from 00:00:00.1 to
59:59:00.1.
For example: 30 seconds
Press [3] [0] [0]
Keys, and then
press ENTER Key
Enter Pulse OFF Time
(min:sec.tenths) 00:00.0
(alternates with)
Then Press ENTER
(min:sec.tenths) 00:00.0
Enter pulse OFF time from 00:00:00.1 to
59:59:00.1.
For example: 7.5 seconds
Press [7] [5] Keys,
and then press
ENTER Key
0:00:00 PROG, START, CLEAR
00:30.0 (MEM.0) 00:07.5
Start sonication in pulsed mode.
(Turn Amplitude Control Knob to desired
level)
Press START Key
STOP
Pulsing 0:00:00
(Elapsed Time begins to count seconds)
To interrupt processing. Press PAUSE Key X:XX:XX
Press PAUSE to Continue
To continue processing. Press PAUSE Key X:XX:XX
(Timer continues to count seconds)
To display parameters of program. Press PROG. Key
DATA
0:00:00 hr:mn:sc X:XX:XX
00:30.0 min:sec 00:07.5
(Then switches back to)
X:XX:XX
(Timer is always counting seconds)
To abort program. Press START Key
STOP
0:00:00 PROG, START, CLEAR
00:30.0 (MEM.0) 00:07.5
When program is completed, exit Press CLEAR Key Press PROG to Program
