Connecting the charging unit
Mitel 612d, 622d, 650c: This handset can be used
without any changes to the charger cradle.
Mitel 632d: To use this handset, you must remove the
two lateral guides in the charger cradle. They are easy to
lift on the inside edge using a fingernail or a paper clip.
The plastic guides can also be removed, by pushing a
suitable screwdriver into the slits on the bottom of the
charger.
Connect the plug-in power supply to the charger cradle
and place the connection cable through the cable guide.
Place the charger cradle on a non-slip surface. Change
the plug of the power supply unit if necessary.
Power Supply / Power unit
The power supply unit is designed for 100V to 240V AC
(50-60 Hz). It is supplied with four change adapters
enabling virtually worldwide use. Where necessary,
connect the plug normally used in your country to the
power supply unit. There are two versions of the plug-in
power supply unit that are connected slightly differently:
Version 1: Press the pushbutton switch on the power
supply unit and push out the existing plug upwards.
Insert the new plug from above into the power supply
unit
Version 2: Remove any existing plug by pressing OPEN.
Then insert the required new plug into the power
supply unit at a slight angle with the label TOP upwards.
Press downwards until it snaps into place
Accessories
The following accessories are available:
Mitel 600c/d charger with international AC-Adapter
Mitel 612d / Handset
Mitel 622d / Handset
Mitel 632d / Handset
Mitel 650c / Handset
Mitel 612d, 622d, 632d, 650c/ Rotary-Belt Clip
Mitel 612d, 622d, 632d, 650c/ Leather Pouch
Neck Band, including band holder for Mitel 632d
Mitel 622d, 632, 650/MicroSD-card
Mitel 600d/c charger Rack with 8 charger cradles
