Installation
Socket connection for a workstation PC (integrated 100Base-T
switch, available on MiVoice 5370 IP and MiVoice 5380 IP)
Handset socket
Headset socket
Power supply socket for connecting a power supply if PoE is
not available
Connect expansion key module MiVoice M530 MiVoice M535
(available on MiVoice 5370 IP and MiVoice 5380 IP)
Integrated switch (MiVoice 5370 IP and MiVoice 5380 IP)
You can use the integrated 100Base-T mini-switch to connect other network terminals (e.g. PC, printer),
thereby reducing the amount of cabling required.
Power supply
If your network supports Power-over-Ethernet, the IP system phone is powered directly via the LAN
connection and there is no need to connect the power supply available as an option.
Release 7.1
159 System Manual for Mitel SMB Controller
