17
Getting Started
13 FXO card with FXO ports RJ-11 connectors offering analog PSTN
access for various VoIP endpoints such
as IP phones, FXS devices, softphones
and IP-based PBX.
14 ETH1 A 10/100/1000 BaseT Ethernet RJ-45
connector for access to a LAN, WAN or
computer. This port is by default used
for uplink / WAN connection.
15 ETH2-ETH3-ETH4/EXT-ET
H5/EXT
10/100/1000 BaseT Ethernet RJ-45
connector for access to a LAN, WAN or
computer. These ports are used by
default for LAN connections.
16 FXS card with FXS ports RJ-11 connectors to attach a
conventional telephone or G3 fax
17 DSP CARD No connector available.
# CONNECTORS/CARDS DESCRIPTION
