1 General configuration
Contents of the Option equipment 1-9
1.4.3 Function extension device
Table 1-4: The list of function extension device
1.4.4 Recommended vision sensors
Table 1-5: List of recommended vision sensors
PoE adapters and cables are required and sold separately. The following adapter and cable are recom-
mended.
PoE adapter: CPS-AC-POE1A-JP (Manufactured by COGNEX)
PoE cable: CCB-84901-2001-## (Manufactured by COGNEX) (## represents the cable length.)
RT ToolBox3 3F-14C-WINE DVD-ROM Windows 7, Windows 8, Windows 8.1, Windows 10
Supporting English.
(With the simulation function)
Ver.1.70Y or later
RT ToolBox3 mini 3F-15C-WINE DVD-ROM
Windows 7, Windows 8, Windows 8.1, Windows 10
Supporting English.
Ver.1.70Y or later
RT VisualBox 3G-30C-WINE CD-ROM
Windows 10
Supporting English.
Easy-setup kit 4F-ASSISTA-
SETUP-JP
For Japan/North America.
A kit which aids setup that consists of switches, a
connector cable, and a 24 V power supply.
4F-ASSISTA-
SETUP-EU
For Europe/China.
Item Type name Specifications Remarks
Force sensor set 4F-FS002H-W200 A set of devices necessary for
force sense control function, such
as a force sensor, an interface
unit, and support software.
Refer to separate volume "Force Sense Function
Instruction Manual" for details.
MELFA-3D Vision 4F-3DVS2-PKG3 A set of devices necessary for the
3D vision sensor function, such
as a 3D camera head.
Refer to separate volume "MELFA-3D Vision
Instruction Manual" for details.
Additional
camera head
2F-3DVS2-OPT3 For the optional visual field
expander.
Power cable: separate wire.
Optional visual
field expander
2F-3DVS2-OPT2 Visual field expansion of 20 to 28
degrees.
-
Type name Manufacturer
Inquiries (As of April
2020)
Remarks
VS80M-202 Mitsubishi Electric Mitsubishi Electric Only available in Japan.
VS80M-202-R Mitsubishi Electric Mitsubishi Electric Supports PatMax RedLine
®
PatMax RedLine
®
cannot be used with RT
VisualBox.
Only available in Japan.
In-Sight 8402M-363-50 COGNEX COGNEX -
In-Sight 8402M-373-50 COGNEX COGNEX Supports PatMax RedLine
®
PatMax RedLine
®
cannot be used with RT
VisualBox.
Item Type Specifications Description
