2 - 14
2 SYSTEM CONFIGURATION
(2) Motion CPU module (Q173DCPU(-S1)/Q172DCPU(-S1))
(a) Rating plate
The rating plate is situated on the side face of the Motion CPU module.
The SERIAL line displays the Motion CPU module serial No.
(b) Front of Motion CPU module
The serial number is displayed on the protruding portion situated on the
lower front side of the Motion CPU module.
Rating plat
erial number
BAT
FRONT
RIO
0
8
C
4
1
2
3
5
6
7
9
A
B
D
E
F
0
8
C
4
1
2
3
5
6
7
9
A
B
D
E
F
12
SW
Q173DCPU-S1
CN1
CAUTI ON
CN2
STOP RUN
EMI
PERIPHERAL I/F
M16349999
(c) System monitor (product information list)
The serial number can be checked on the system monitor screen in
GX Works2/GX Developer. (Refer to Section 2.2.2.)
REMARK
The serial number display was corresponded from the Motion CPU modules
manufactured in early October 2007.
