9 DIMENSIONS
9.2 MR-CV30K(4)/MR-CV37K(4)/MR-CV45K(4)
85
9
9.2 MR-CV30K(4)/MR-CV37K(4)/MR-CV45K(4)
[Unit: mm]
L21
L11
PE
TE3
L-
L+
TE2
TE1
L1 L2 L3
45 45
380
360
178
132
10
10
66
155 195
200
180
6
TE1
PE
TE2
TE3
92
37.51.5
124.5
11
24
100
178.5
175.5
26
108
88
113.5
60
150
49 52
150
2-φ6 mounting hole
Approx.
80
Cooling
fan
exhaust
Intake
Terminal
Mounting screw
Screw size: M5
Tightening torque: 3.24 [N•m]
TE1 Screw size: M8
Tightening torque: 6.0 [N•m]
TE2 Screw size: M6
Tightening torque: 3.0 [N•m]
TE3 Screw size: M4
Tightening torque: 1.2 [N•m]
PE Screw size: M8
Tightening torque: 6.0 [N•m]
Mass: 12.1 [kg]
