6.31 CH5 D/A Conversion Scaling Enable/Disable Setting (Un\G810)
Whether to enable or disable a scaling conversion of digital input values is set. (Refer to
Section 4.3.4.)
For information on the buffer memory for CH6, refer to Section 6.1 (2).
(1) Setting method
(a) Set whether to enable or disable the D/A conversion scaling by using the buffer
memory.
(b) Set Operating condition setting request (Y9) to on to activate the setting. (Refer to
Section 5.2.2 (3).)
(2) Default
The D/A conversion scaling is disabled (1) for all the channels (CH5 and CH6) in
default configuration.
Table 6.24 CH5 D/A conversion scaling enable/disable setting (Un\G810)
Setting value Description
0
D/A conversion scaling
enabled
1
D/A conversion scaling
disabled

Mitsubishi Electric Q64AD2DA Specifications

General

Product Series	Q Series
Number of Channels	4
Input Channels	4
Output Channels	2
Operating Temperature	0 to 55°C
Storage Temperature	-25 to 75°C
Type	Analog I/O Module
Input Signal Range	Voltage: -10 to +10 V, Current: 4 to 20 mA
Output Signal Range	Voltage: -10 to +10 V, Current: 4 to 20 mA
Resolution	1/4000
Isolation	Photocoupler isolation between input/output
Power Supply	5V DC (supplied from the base unit)
Input Range	Voltage: -10 to +10 V, Current: 4 to 20 mA
Output Range	Voltage: -10 to +10 V, Current: 4 to 20 mA
Conversion Speed	1 ms/channel
Weight	0.2 kg
