6
The following RS-232 interface connector is used for the AJ65BT-
R2N.
• DDK Ltd.
9-pin D-sub (female) screw type
17JE-13090-37 (D23A)
For the AJ65BT-R2N side cable, use a connector shell appropriate
to the above.
The screw size for the connector is M2.6.
Use the following model as a connector shell of the AJ65BT-R2N
side connection cable.
• DDK Ltd.
Plug, shell: 17JE-23090-02 (D8A) (-CG)
2.4.2 RS-232 cable specifications
Use an RS-232 cable that is compliant with the RS-232 standard, in a
length of 15m or less.
(Recommended cable)
• Oki Electric Cable Co., Ltd.
7/0.127 P HRV-SV ( :Specify the number of pairs.)
