6. EXTERNAL DIMENSIONS
Figure 6.1 External dimensions
47.5
(1.87)
9
(0.35)
47
(1.85)
4.5
(0.18)
161 (6.33)
170 (6.69)
2- 4.5 installation hole
4.5
(0.18)
71 (2.79)
80 (3.14)
Center of DIN rail
Unit: mm (inch
)
