Mitsubishi AJ65BT-R2N-U-HW User Manual

7
2.5 General-purpose I/O Specifications
A terminal name of the general-purpose I/O terminal block and general-
purpose output specifications have been changed from hardware
version B.
For products of hardware version A, refer to the following manual.
CC-Link System RS-232 Interface Module User's Manual
(Nonprocedural Protocol Mode)
(1) General-purpose I/O terminal block
The following explains the general-purpose I/O terminal block.
Figure 2.2 General-purpose I/O terminal block
XC XD YC
COM1 COM2NC
YD

Mitsubishi AJ65BT-R2N-U-HW Specifications

General

Brand	Mitsubishi
Model	AJ65BT-R2N-U-HW
Category	Controller
Language	English
