2 - 1

MELSEC-A

2 SYSTEM CONFIGURATION

This chapter describes the system configuration for use of the AJ65SBT-64AD.

2.1 Overall Configuration

The overall configuration for use of the AJ65SBT-64AD is shown below.

CC-Link master/local module (local station)

(AJ61BT11, A1SJ61BT11, AJ61QBT11, A1SJ61QBT11, QJ61BT11)

CC-Link dedicated cable

(Intelligent device station) (Remote I/O station)

(Remote device station)

AJ65SBT-64AD

(Remote device station)

1 station occupied

RX/RY: 32 points each

RWr/RWw: 4 points each

Object whose

voltage/current

will be detected

Terminal resistor

CC-Link master/local module (master station)

(AJ61BT11, A1SJ61BT11, AJ61QBT11,

A1SJ61QBT11, QJ61BT11)
