3 - 13
MELSEC-A
3 SPECIFICATION
3.6 Remote Register
The AJ65SBT-64AD has a remote resister for data communication with the master
module. The remote register allocation and data structures are described.
3.6.1 Remote register allocation
The remote register allocation is shown in Table 3.6.
Table 3.6 Remote register allocation
Communication direction Address Description Default value Reference section
RWwm A/D conversion enable/prohibit specification 0 Section 3.6.2
RWwm+1 Input range setting 0 Section 3.6.3
RWwm+2 Moving average processing count setting 0 Section 3.6.4
Master Remote
RWwm+3 Reserved 0 ——
RWrn CH.1 digital output value 0
RWrn+1 CH.2 digital output value 0
RWrn+2 CH.3 digital output value 0
Remote
Master
RWrn+3 CH.4 digital output value 0
Section 3.6.5
m, n: Address allocated to the master module by the station number setting.
POINT
Do not read or write data from or to the reserved area of the remote register. If data
is read or written, we cannot guarantee the functions of the AJ65SBT-64AD.
To Next Page
