Mitsubishi AL-10MR-D Hardware Manual

α
Simple Application Controller
Hardware Specification 2
4
ENG
2.2 Power Supply Specification
Table 2.2: Power Supply Specifications
Description Code Specification
Power Supply
AL -***-A 100 - 240V AC~, +10% -15%, 50 - 60 Hz
AL-***-D 24V DC, +20% -15%
Maximum Momentary Power
Failure
AL-***-A 10ms
AL-***-D 5ms
In-rush Current
240V AC~ (120V AC~) <
1.5 Amp (0.7 Amp)
24 V DC <
7.0 Amp
Maximum Power Consumption
(without Special Connection
Modules)
AL-6MR-A, 264V AC~ 3.0 W
AL-10MR-A, 264V AC~ 4.0 W
AL-10MR-D, 28.8V DC 3.0 W
AL-10MT-D, 28.8V DC 2.0 W
AL-20MR-A, 264V AC~ 8.0 W
AL-20MR-D, 28.8V DC 7.0 W
AL-20MT-D, 28.8V DC 5.0 W

Mitsubishi AL-10MR-D Specifications

General

Brand	Mitsubishi
Model	AL-10MR-D
Category	Controller
Language	English
