α
Simple Application Controller
Hardware Specification 2
6
ENG
2.3 Input Specification
Note 1 - Current leakage from the sensors connected to the inputs might provide enough current to turn the
controller On. Do not use two wire sensors.
Table 2.3: AC Input Specifications
Description AC Input Specification
Input Voltage 100 - 240V AC~, +10% -15%, 50 - 60 Hz
Input Current 0.24mA / 240V AC~, see Note 1
Input Impedance >
800 kOhms
OFF to ON/ ON to OFF 80V/40V
Response Time ~ 50ms
Isolation Circuit None
Operation Indication Liquid Crystal Display
Table 2.4: DC Input Specifications
Description Sink (“-” Common) Source (“+” Common)
Input Voltage 24V DC +20% -15% 24V DC +20% -15%
Input Current 5.0 mA / 24V DC 5.0 mA / 24V DC
OFF to ON/ ON to OFF
Current: >
4.3mA / < 1.1 mA
Voltage: <
4V / > 18V
Voltage: > 18V / < 4V
Response Time (I01 - I08) 10 - 20 ms 10 - 20 ms
Response Time (I09 - I12) 20 - 40 ms 20 - 40 ms
Isolation Circuit None None
Operation Indication Liquid Crystal Display
