4.7 Output Relay and Transistor Wiring
4.7.1 Relay Output Wiring Diagram (AC and/or DC)
Table 4.4: Relay Output Wiring
Ref. Item Description
1
α
Base Unit
2 Mutually exclusive outputs
3 Output Devices
4
Circuit Protection Device - Limit
to 10 Amps per every four out-
put terminals used.
5 Emergency Stop
6 DC Power Supply
7 AC Power Supply
"!
$
OUT1
##
%
&
OUT2 OUT3 OUT4
(
$
%
+
