2. Disconnect the connector (B).
3. Unhook the spring (C) which secures the
bulb, and then remove the headlamp bulb.
CAUTION
l
Handle halogen lamp bulb with care. The
gas inside halogen lamp bulb is highly
pressurized, so dropping, knocking, or
scratching a halogen lamp bulb can cause
it to shatter.
l
Never hold the halogen lamp bulb with a
bare hand, dirty glove, etc.
The oil from your hand could cause the
bulb to break the next time the head-
lamps are operated.
If the glass surface is dirty, it must be
cleaned with alcohol, paint thinner, etc.,
and refit it after drying it thoroughly.
4. To install the bulb, perform the removal
steps in reverse.
NOTE
l
When installing the bulb, align the upper part
as illustrated then press the bulb into place.
To Next Page
