Engine specifications
E01100602386
Item 1100 models 1300 models 1500 models
Engine type
Three-cylinder, in line, water cooled
four-cycle, double overhead camshaft
Four-cylinder, in line, water cooled
four-cycle, double overhead camshaft
Four-cylinder, in line, water cooled four-
cycle, double overhead camshaft with in-
tercooler and turbocharger
Engine model
134910 3A91 135930 4A90
4G15
Total displacement
1,124 cc 1,332 cc
1,468 cc
Bore 75.0 mm 75.0 mm 75.5 mm
Stroke
84.8 mm 75.4 mm
82.0 mm
Compression ratio
10.5 11.0 10.5 11.0
9.0
Valve clearance
Intake 0.18 - 0.26 mm (cold) Automatically
Exhaust 0.26 - 0.34 mm (cold) Automatically
Firing order 1-3-2 1-3-4-2
Maximum output (EEC net) 55 kW/6.000 r/min 70 kW/6.000 r/min 110 kW/6.000 r/min
Maximum torque (EEC net) 100 Nm/4,000 r/min 125 Nm/4,000 r/min 210 Nm/3,500 r/min
Specifications
9-09
9
