Use the manual Beichen Automation BCNET-FX-S Ethernet communication processor
2.3.2 serial interface x 2
The X 2 is the MD8 bus port, which connects directly to the touch screen's communication port
through the communication line. The pin is defined as:
1 foot
RXD
-
2 feet
RXD
+
3 feet
GND
4 feet
Txd -
7 feet
TXD
+
The baud rates supported by the X2 interface are: 9.6K, 19.2K, 38.4K, 115.2K.
2.3.3 Ethernet communication port X 3
Ethernet communication RJ45 * 2 standard socket, following the Ethernet wiring
standard, the PIN is defined as:
1 foot
TX
+
2 feet
TX
T -
3 feet
Rx
+
6 feet
RX
-
With Green Link Light, orange Active light. Support 10100m baud rate adaptive,
support line sequence (cross t568adirect T568B) adaptive.
2.3.4 Ethernet communication port X 4
Ethernet communication RJ45 standard Jack, following the Ethernet wiring standard,
the PIN is defined as:
1 foot
TX
+
2 feet
TX
T -
3 feet
Rx
+
6 feet
RX
-
With Green Link Light, orange Active light. Support 10100m baud rate adaptive,
support line sequence (cross t568adirect T568B) adaptive.
The above Ethernet ports all have switch functions and can be used as three-port
switches.
