FX1N Series Programmable Controllers Diagnostics 7.
7-11
1
2
3
4
5
6
7
7.10 Device List
Item Specification Remarks
Program capacity 8k steps
Provided by built in EEPROM
momory
I/O configuration
Max hardware I/O configuration points 128, dependent on user selection
(Max. software addressable Inputs 128, Outputs 128)
Auxiliary relay
(M coils)
General 384 points M0 to M383
Latched
(EEPROM
backed-up)
1152 points
EEPROM keep: 128 points
Capacitor keep: 1024 points
M384 to M1535
EEPROM keep: M384 to M511
Capacitor keep: M512 to M1535
Special 256 points From the range M8000 to M8255
State relays
(S coils)
Latched
(EEPROM
backed-up)
1000 points
EEPROM keep: 128 points
Capacitor keep: 872 points
S0 to S999
EEPROM keep: S0 to S127
Capacitor keep: S128 to S999
Initial 10 points (subset) S0 to S9
Timers (T)
100 msec
200 points
Range: 0 to 3,276.7 sec
T0 to T199
10 msec
46 points
Range: 0 to 327.67 sec
T200 to T245
1 msec
retentive
4 point, Capacitor keep
Range: 0 to 32.767 sec
T246 to T249
100 msec
retentive
6 points, Capacitor keep
Range: 0 to 3,276.7 sec
T250 to T255
