FX1N Series Programmable Controllers Power Supply 4.
4-2
4.3 Power Supply
• When wiring an AC supply, the “Live” cable should be connected to the “L” terminal and the
“Neutral” cable should be connected to the “N” terminal. Do NOT connect the “Live” wire to
the “N” terminal, otherwise, the user may receive a dangerous shock upon powerup.
• When wiring a DC supply the “Live” cable should be connected to the “+” terminal and the
“Neutral” cable should be connected to the “-” terminal. Do NOT connect the “Live” wire to
the “-” terminal, otherwise, the user may receive a dangerous shock upon powerup.
