6. Outputs
6.1 Output Specifications
Description Relay Output Transistor Output
Switched voltages (resistive load)
≤
240V AC,
≤
30V DC
5-30V DC
Rated current / N points (resistive
load)
2A/1 point,
8A/COM
0.5A/1 point,
0.8A/COM
Max. Inductive load 80VA, 120/240V AC 12W/24V DC
Minimum load
When supply voltage < 5V DC
allow at least 2mA flow
-
Response time
(approx.)
OFF
→
ON 10ms
< 0.2ms;
< 5
µ
s (Y000,Y001 only)
ON
→
OFF 10ms
< 0.2ms (I > 0.2A);
<5
µ
s (Y000,Y001 only)
Circuit isolation By Relay By Photo Coupler
Open circuit current leakage - 0.1mA/30V DC
Operation indication LED is lit when coil is energized
Output protection
Internal device None
Outside device
(Fuse)
Rated value according to the load.
FX1N Series Programmable Controllers
