10 Buffer Memory

10.4 I/O signals to PLC

102

FX3U-16CCL-M User's Manual

•PLC → Master block : Write (when TO instruction is used)

BFM No.

Bit Output signal name

Hex. Dec.

#AH #10

b0 Refresh command

Use prohibited

b6 Request for data link startup by buffer memory parameters

Use prohibited

b10

b11

b12

b13

b14

b15

#BH #11

Use prohibited

b10

b11

b12

b13

b14

b15
