16 Troubleshooting
16.3 Troubleshooting by Error Code
242
FX3U-16CCL-M User's Manual
16.3 Troubleshooting by Error Code
1. Error codes detected by the FX3U-16CCL-M
BFM#29 stores the error code detected by the FX3U-16CCL-M.
→ For details error code, refer to Subsection 10.5.1.
2. The error code on the CC-Link network
The error code stored in the link special register (SW) is shown below.
Error
code
(Hex.)
Error definition The cause of the error occurrence (details) Error corrective action
B110
Transient data can not be
received.
A line error has occurred. Check the line.
B111
Transient data receiving
order error
A line error has occurred. Check the line.
B112 Transient data length error A line error has occurred. Check the line.
B113 Transient data ID error A line error has occurred. Check the line.
B115 Link error A line error has occurred. Check the line.
B201
Corresponding station error
during sending
A data link error occurred at the corresponding station
during transient transmission.
Check the communication status of
other stations, whether or not a
temporary error invalid station is
specified, or if the corresponding
station is stopped.
B205 Transient target station error
A transient request was issued to other than the
intelligent device station.
Check the target station.
B301
Request for processing
during link stop
The request for line test was given while link was
stopped.
Execute the line test while link is
executed.
B302
Specified station number
setting error
When the request for temporary error invalid station or
the request for cancel of temporary error invalid
station was given, the specified station number was
beyond the maximum communication station number.
Specify a station number not more
than the maximum communication
station number.
B303
Specified station number no-
setting error
When the request for temporary error invalid station or
the request for cancel of temporary error invalid
station was given, the station number was not
specified.
Specify a station number.
(SW0003, SW0004)
B304
Line test error station
detected
An error was detected in a remote station and
intelligent device station when a line test was
performed.
Check that the remote station and
intelligent device station is
operational and that the cable is not
disconnected.
B305
Line test error station
detected
(Response data error)
An error was detected in response data error when a
line test was performed.
Change the remote device stations/
intelligent device stations.
B306 Specified station setting error
When the request for temporary error invalid station or
the request for cancel of temporary error invalid
station was given, a head station was not specified.
Specify a head station in giving the
request for temporary error invalid
station or the request for cancel of
temporary error invalid station.
B307 Data link error in all stations
When the following request was given, there was data
link error in all stations.
• Data link restart (SB0000)
• Data link stop (SB0002)
Wait until the data link becomes
normal, then give the request again.
B308
Station number setting error
(loading status)
The station number of a slave station is not set inside
the range from 1 to 16.
Set a slave station number inside the
specification range (1 to 16).
B309 Station number overlap error
In connected units, a station number overlaps
(including the number of occupied stations, excluding
overlap of a head station number).
Check the station numbers of the
units. (Including the number of
occupied stations.)
B30A
Loading/ parameter
consistency error
The station type is different between the unit and the
parameter.
Set the parameter correctly.
B30B
Loading/ parameter
consistency error
The loading status is not consistent with the network
parameters.
Align the loading status with the
network parameters.
B30D Initial status
Data link restart (SB0000) or data link stop (SB0002)
was issued being initial processing.
Issue the request after the data link
is started.
To Next Page
