10 Buffer Memory
10.9 [BFM#480 to #543] Remote registers (RWw)
113
FX3U-16CCL-M User's Manual
1
Introduction
2
Specification
3
System Configuration
4
Installation
5
Wiring
6
Introduction of Functions
7
Data Link Processing Time
8
Parameter Setting
9
Data Link Procedure
10
Buffer Memory
Correspondence among BFM No. in master station, station number and remote register (RWw)
number
Station
No.
BFM No. Remote register No.
Station
No.
BFM No. Remote register No.
1
1E0H RWw 0
9
200H RWw 20
1E1H RWw 1 201H RWw 21
1E2H RWw 2 202H RWw 22
1E3H RWw 3 203H RWw 23
2
1E4H RWw 4
10
204H RWw 24
1E5H RWw 5 205H RWw 25
1E6H RWw 6 206H RWw 26
1E7H RWw 7 207H RWw 27
3
1E8H RWw 8
11
208H RWw 28
1E9H RWw 9 209H RWw 29
1EAH RWw A 20AH RWw 2A
1EBH RWw B 20BH RWw 2B
4
1ECH RWw C
12
20CH RWw 2C
1EDH RWw D 20DH RWw 2D
1EEH RWw E 20EH RWw 2E
1EFH RWw F 20FH RWw 2F
5
1F0H RWw 10
13
210H RWw 30
1F1H RWw 11 211H RWw 31
1F2H RWw 12 212H RWw 32
1F3H RWw 13 213H RWw 33
6
1F4H RWw 14
14
214H RWw 34
1F5H RWw 15 215H RWw 35
1F6H RWw 16 216H RWw 36
1F7H RWw 17 217H RWw 37
7
1F8H RWw 18
15
218H RWw 38
1F9H RWw 19 219H RWw 39
1FAH RWw 1A 21AH RWw 3A
1FBH RWw 1B 21BH RWw 3B
8
1FCH RWw 1C
16
21CH RWw 3C
1FDH RWw 1D 21DH RWw 3D
1FEH RWw 1E 21EH RWw 3E
1FFH RWw 1F 21FH RWw 3F
