10 Buffer Memory
10.10 [BFM#736 to #799] Remote registers (RWr)
115
FX3U-16CCL-M User's Manual
1
Introduction
2
Specification
3
System Configuration
4
Installation
5
Wiring
6
Introduction of Functions
7
Data Link Processing Time
8
Parameter Setting
9
Data Link Procedure
10
Buffer Memory
Correspondence among BFM No. in master station, station number and remote register (RWr)
number
Station
No.
BFM No. Remote register No.
Station
No.
BFM No. Remote register No.
1
2E0H RWr 0
9
300H RWr 20
2E1H RWr 1 301H RWr 21
2E2H RWr 2 302H RWr 22
2E3H RWr 3 303H RWr 23
2
2E4H RWr 4
10
304H RWr 24
2E5H RWr 5 305H RWr 25
2E6H RWr 6 306H RWr 26
2E7H RWr 7 307H RWr 27
3
2E8H RWr 8
11
308H RWr 28
2E9H RWr 9 309H RWr 29
2EAH RWr A 30AH RWr 2A
2EBH RWr B 30BH RWr 2B
4
2ECH RWr C
12
30CH RWr 2C
2EDH RWr D 30DH RWr 2D
2EEH RWr E 30EH RWr 2E
2EFH RWr F 30FH RWr 2F
5
2F0H RWr 10
13
310H RWr 30
2F1H RWr 11 311H RWr 31
2F2H RWr 12 312H RWr 32
2F3H RWr 13 313H RWr 33
6
2F4H RWr 14
14
314H RWr 34
2F5H RWr 15 315H RWr 35
2F6H RWr 16 316H RWr 36
2F7H RWr 17 317H RWr 37
7
2F8H RWr 18
15
318H RWr 38
2F9H RWr 19 319H RWr 39
2FAH RWr 1A 31AH RWr 3A
2FBH RWr 1B 31BH RWr 3B
8
2FCH RWr 1C
16
31CH RWr 3C
2FDH RWr 1D 31DH RWr 3D
2FEH RWr 1E 31EH RWr 3E
2FFH RWr 1F 31FH RWr 3F
