2 Specification
2.3 Performance Specification
22
FX3U-16CCL-M User's Manual
*1. Indicates the number of link points for remote net ver.1 mode. For the number of link points for remote
net ver.2 mode/remote net additional mode, refer to the following table.
*2. CC-Link dedicated cables, Ver. 1.10 compatible CC-Link dedicated cable and CC-Link dedicated
high-performance cable cannot be used together. Also attach the terminating resister which matches
the kind of the cable.
*3. For details of other applied instructions and methods, refer to the FX
3G/FX3U/FX3UC Programming
Manual.
• Link points of remote net ver. 2 mode and remote net additional mode
Communication with PLC
By FROM and TO instructions or direct specification of buffer memory (FX3U/FX3UC) via
the buffer memory
*3
Number of I/O occupied points 8 points
Number of connectable units to the main unit 1 (An FX3U-16CCL-M cannot be attached to main unit with an FX2N-16CCL-M.)
CC-Link Version CC-Link Ver. 1.10 CC-Link Ver. 2.00
Expanded cyclic setting - Single Double Quadruple Octuple
Occupies
1 station
bit (RX) 32 points 32 points 32 points 64 points 128 points
bit (RY) 32 points 32 points 32 points 64 points 128 points
word (RWw) 4 points 4 points 8 points 16 points 32 points
word (RWr) 4 points 4 points 8 points 16 points 32 points
Occupies
2 stations
bit (RX) 64 points 64 points 96 points 192 points
-
bit (RY) 64 points 64 points 96 points 192 points
word (RWw) 8 points 8 points 16 points 32 points
word (RWr) 8 points 8 points 16 points 32 points
Occupies
3 stations
bit (RX) 96 points 96 points 160 points
--
bit (RY) 96 points 96 points 160 points
word (RWw) 12 points 12 points 24 points
word (RWr) 12 points 12 points 24 points
Occupies
4 stations
bit (RX) 128 points 128 points 224 points
--
bit (RY) 128 points 128 points 224 points
word (RWw) 16 points 16 points 32 points
word (RWr) 16 points 16 points 32 points
Item Specification
