2 Specification
2.5 Maximum Transmission Distance
24
FX3U-16CCL-M User's Manual
• CC-Link dedicated high-performance cable (requiring terminal resistor of 130 )
2. In the system consisting of remote I/O stations, remote device stations and intelligent
device stations
*1. Cable length between remote I/O or remote device stations
*2. Cable length between the master station or intelligent device stations and an adjacent station
• CC-Link dedicated cable (requiring terminal resistor of 110 )
• CC-Link dedicated high-performance cable (requiring terminal resistor of 130 )
*3. The cable length between remote I/O stations or remote device stations is within this range and if
even one location is wired, the maximum overall cable distance will be as indicated above.
Transmission speed
Cable length between stations
Maximum transmission
distance
*1 *2
156 kbps
30 cm or more 1 m or more
1200 m
625 kbps 900 m
2.5 Mbps 400 m
5M bps 160 m
10M bps 100 m
Transmission speed
Cable length between stations
Maximum transmission
distance
*1 *2
156 kbps
30 cm or more
2 m or more
1200 m
625 kbps 600 m
2.5 Mbps 200 m
5 Mbps
30 cm to 59 cm
*3
110 m
60 cm or more 150 m
10 Mbps
30 cm to 59 cm
*3
50 m
60 cm to 99 cm
*3
80 m
1 m or more 100 m
Transmission speed
Cable length between stations
Maximum transmission
distance
*1 *2
156 kbps
30 cm or more
2 m or more
1200 m
625 kbps 600 m
2.5 Mbps 200 m
5 Mbps
30 cm to 59 cm
*3
110 m
60 cm or more 150 m
10 Mbps
70 cm to 99 cm
*3
50 m
1 m or more 100 m
Master station
Remote I/O station
or remote device
station
Remote I/O station
or remote device
station
Intelligent device
station
Intelligent device
station
*2 *1 *2 *2
Maximum transmission distance
