Mitsubishi FX3U-16CCL-M User Manual

6 Introduction of Functions
6.2 Basic Functions
55
FX3U-16CCL-M User's Manual
1
Introduction
2
Specification
3
System Configuration
4
Installation
5
Wiring
6
Introduction of Functions
7
Data Link Processing Time
8
Parameter Setting
9
Data Link Procedure
10
Buffer Memory
Word information from the master station to the remote device station/intelligent device station
7) The PLC writes the word information to be transmitted to the remote device station and the intelligent
device station to the buffer memory "remote register (RWw)" in the master station using the TO
instruction.
8) The information of the buffer memory "remote register (RWw)" is automatically (for each link scan) stored
in the remote register (RWw) in the remote device station and the intelligent device station.
Master station
Remote device station
(Station No. 1:
Occupies 1 station)
RWw 0
RWw 1
RWw 2
RWw 3
RWw 4
RWw 5
RWw 6
RWw 7
RWw 8
RWw 9
RWw 3E
RWw 3F
...
Remote register (RWw)
RWw 0
RWw 1
RWw 0
RWw 1
Intelligent device station
(Station No. 2:
Occupies 1 station,quadruple)
RWw 2
RWw 3
RWw 4
RWw 5
RWw 6
RWw 7
RWw 3D
RWw 2
RWw 3
RWw A
RWw B
RWw C
RWw D
RWw E
RWw F
RWw 10
RWw 11
RWw 12
RWw 13
RWw 3C
Remote register (RWw)
Remote register (RWw)
TO
7)
PLC
8)
8)
RWw 8
RWw 9
RWw A
RWw B
RWw C
RWw D
RWw E
RWw F
