6 Introduction of Functions
6.4 Handy Functions
66
FX3U-16CCL-M User's Manual
• Link special register (SW)
SW No.
BFM No.
Name Description
Hex. Dec.
SW0003 603H 1539
Specification of multiple temporary
error invalid stations
Selects whether or not to specify two or more temporary error
invalid stations.
00: Specifies two or more stations stored in SW0004.
1 to 16: Specifies a single station whose station number is 1 to
16.
(The number indicates the station number of a temporary error
invalid station.)
SW0004 604H 1540
Temporary error invalid station
specification
Specifies temporary error invalid stations.
0: Does not specify as temporary error invalid station.
1: Specifies as temporary error invalid station.
Numbers 1 to 16 above indicate station numbers.
(Only the bit corresponding to the head station number is set to
ON.)
Error invalid stations, reserved stations and any station of the
number higher than the max. are not specified.
SW0049 649H 1609
Result of request for temporary
error invalid stations
Stores the execution result of request for temporary error invalid
stations by SB0004.
0: Normal
Other than 0: Stores the error code (Refer to Section 16.3.).
SW004B 64BH 1611
Result of request for cancel of
temporary error invalid stations
Stores the execution result of request for cancel of temporary
error invalid stations by SB0005.
0: Normal
Other than 0: Stores the error code (Refer to Section 16.3.).
SW007C 67CH 1660
Temporary error invalid station
specification status
Stores the temporary error invalid station specification status.
0: Normal status
1: Temporary error invalid status
Numbers 1 to 16 above indicate station numbers.
(Bits corresponding to as many as the number of occupied
stations are set to ON.)
Error invalid stations, reserved stations and any station of the
number higher than the max. are excepted.
16 15 14 13 to 4 3
b15b14b13b12 to b3 b2
2 1
b1 b0
SW0004
16 15 14 13 to 4 3
b15b14b13b12 to b3 b2
2 1
b1 b0
SW007C
To Next Page
