Mitsubishi FX3U-485-BD User Manual

E-148
FX Series PLC User's Manual - Data Communication Edition
Inverter Communication
12 Related Data
12.5 FREQROL Inverter Parameter List
12.5.2 Parameters in F700, A700, E700 and D700 Series
The following parameters are provided in the F700, A700, E700 and D700 Series inverters. (For details, make
sure to refer to the respective inverter manual.)
FREQROL F700 Series FREQROL A700 Series FREQROL E700 Series FREQROL D700 Series
Function
Pr
No.
Name
Pr
No.
Name
Pr
No.
Name
Pr
No.
Name
Basic functions
0 Torque boost 0 Torque boost 0 Torque boost 0 Torque boost
1 Maximum frequency 1 Maximum frequency 1 Maximum frequency 1 Maximum frequency
2 Minimum frequency 2 Minimum frequency 2 Minimum frequency 2 Minimum frequency
3 Base frequency 3 Base frequency 3 Base frequency 3 Base frequency
4
Multi−speed setting
(high speed)
4
Multi-speed setting
(high speed)
4
Multi-speed setting
(high speed)
4
Multi-speed setting
(high speed)
5
Multi−speed setting
(middle speed)
5
Multi-speed setting
(middle speed)
5
Multi-speed setting
(middle speed)
5
Multi-speed setting
(middle speed)
6
Multi−speed setting
(low speed)
6
Multi-speed setting
(low speed)
6
Multi-speed setting
(low speed)
6
Multi-speed setting
(low speed)
7 Acceleration time 7 Acceleration time 7 Acceleration time 7 Acceleration time
8 Deceleration time 8 Deceleration time 8 Deceleration time 8 Deceleration time
9
Electronic thermal
O/L relay
9
Electronic thermal
O/L relay
9
Electronic thermal
O/L relay
9
Electronic thermal
O/L relay
DC injection
brake
10
DC injection brake
operation frequency
10
DC injection brake
operation frequency
10
DC injection brake
operation frequency
10
DC injection brake
operation frequency
11
DC injection brake
operation time
11
DC injection brake
operation time
11
DC injection brake
operation time
11
DC injection brake
operation time
12
DC injection brake
operation voltage
12
DC injection brake
operation voltage
12
DC injection brake
operation voltage
12
DC injection brake
operation voltage
− 13 Starting frequency 13 Starting frequency 13 Starting frequency 13 Starting frequency
− 14 Load pattern selection 14 Load pattern selection 14 Load pattern selection 14 Load pattern selection
Jog operation
15 Jog frequency 15 Jog frequency 15 Jog frequency 15 Jog frequency
16
Jog acceleration/
deceleration time
16
Jog acceleration/
deceleration time
16
Jog acceleration/
deceleration time
16
Jog acceleration/
deceleration time
− 17 MRS input selection 17 MRS input selection 17 MRS input selection 17 MRS input selection
− 18
High speed maximum
frequency
18
High speed maximum
frequency
18
High speed maximum
frequency
18
High speed maximum
frequency
− 19 Base frequency voltage 19 Base frequency voltage 19 Base frequency voltage 19 Base frequency voltage
Acceleration/
deceleration
times
20
Acceleration/
deceleration reference
frequency
20
Acceleration/
deceleration reference
frequency
20
Acceleration/
deceleration reference
frequency
20
Acceleration/
deceleration reference
frequency
21
Acceleration/
deceleration time
increments
21
Acceleration/
deceleration time
increments
21
Acceleration/
deceleration time
increments
- −
Stall prevention
22
Stall prevention
operation level
22
Stall prevention
operation level
(torque limit level )
22
Stall prevention
operation level
22
Stall prevention
operation level
23
Stall prevention
operation level
compensation factor at
double speed
23
Stall prevention
operation level
compensation factor at
double speed
23
Stall prevention
operation level
compensation factor at
double speed
23
Stall prevention
operation level
compensation factor at
double speed
Multi−speed
setting
24
Multi-speed setting
(speed 4)
24
Multi-speed setting
(speed 4)
24
Multi-speed setting
(speed 4)
24
Multi-speed setting
(speed 4)
25
Multi-speed setting
(speed 5)
25
Multi-speed setting
(speed 5)
25
Multi-speed setting
(speed 5)
25
Multi-speed setting
(speed 5)
26
Multi-speed setting
(speed 6)
26
Multi-speed setting
(speed 6)
26
Multi-speed setting
(speed 6)
26
Multi-speed setting
(speed 6)
27
Multi-speed setting
(speed 7)
27
Multi-speed setting
(speed 7)
27
Multi-speed setting
(speed 7)
27
Multi-speed setting
(speed 7)
− 28
Multi-speed input
compensation selection
28
Multi-speed input
compensation selection
- − - −
