H-28
FX Series PLC User's Manual - Data Communication Edition
Programming Communication
4 Connection Cables and Interfaces
4.1 Simplified Tables
4.1.2 Cable combination simplified table
From the shape of the programming tool connector and PLC connector, combinations of the cable, converter
and communication equipment can be checked.
Interface RS-422 RS-232C USB
Standard port
FX
0,FX0S,FX0N
FX1S,FX1N,FX2N
FX1NC,FX2NC
FX3G,FX3U
FX3UC
FX1,FX2(FX)
FX
2C,A,QnA
— —FX3G
Communication
equipment
FX
1N-422-BD
FX
2N-422-BD
FX
3G-422-BD
FX
3U-422-BD
—
FX
1N-232-BD
FX
2N-232-BD
FX
3G-232-BD
FX
3U-232-BD
FX
2NC-232ADP
FX
3U-232ADP
(-MB)
FX
0N-232ADP FX3U-USB-BD
Connector in PLC
8-pin MINI-DIN,
female
3
2
1
5
4
8
7
6
25-pin D-Sub,
female
13 1
25 14
9-pin D-Sub,
male
5
1
96
25-pin D-Sub,
female
13 1
25 14
5-pin MINI-USB
B plug, female
