Mitsubishi LANCER EVOLUTION 2003

INSTALLATION AND REMOVAL OF ADHESIVE COMPONENTS
REFERENCE MATERIAL
8-6
ADHESIVE TAPE POSITION
REMOVAL
.
Gently lift and remove the side air dam. If there is any double-
side tape remaining on the side air dam, remove according to
the following instructions.
<Remove double-side tape remaining on the body
surface>
AB202318
AB
ADHESIVE TAPE: DOUBLE-SIDED TAPE [ 5 mm (0.20 in) WIDTH AND 1.2 mm (0.05 in) THICKNESS ]
SIDE AIR DAM
DOUBLE-SIDED TAPE
AB202335
AB
ADHESIVE TAPE:
DOUBLE-SIDED TAPE A: [5 mm ( 0.2 in ) WIDTH AND 0.8 mm ( 0.03 in ) THICKNESS ]
B: [5 mm ( 0.2 in ) WIDTH AND 1.2 mm ( 0.05 in ) THICKNESS ]
A
B
DOUBLE-SIDED TAPE
REAR SPOILER
<TYPE A>
AB202336
AB
ADHESIVE TAPE: DOUBLE-SIDED TAPE [ 3 mm ( 0.12 in ) THICKNESS ]
DOUBLE-SIDED TAPE
DOUBLE-SIDED
TAPE
DOUBLE-SIDED
TAPE
REAR SPOILER
<TYPE B>
