INSTALLATION AND REMOVAL OF ADHESIVE COMPONENTS
REFERENCE MATERIAL
8-7
1. Attach protection tape all the way along the edges of the
double-sided tape which is still adhering to the body.
2. Scrape off the double-sided tape with a resin spatura as
possible.
3. Peel off the protection tape.
4. Use a shop towel moistened with 3M AAD Part number
8906 or equivalent to wipe the body.
.
<Remove double-side tape remaining on side air dam and
adhere double-side tape (when re-using side air dam)>
1. Scrape off the double-sided tape on the side air dam with a
resin spatura as possible.
2. Use a shop towel moistened with 3M AAD Part number
8906 or equivalent to wipe the side air dam surface.
3. Remove only a small portion of the residual adhesive.
4. Adhere the double-side tape as specified on the side air
dam.
INSTALLATION
.
1. Tear off the double-sided tape backing paper.
NOTE: If you attach the adhesive tape to the edge of the
backing paper, it will be easy to tear off.
2. Install the side air dam.
NOTE: If the double-sided tape is difficult to affix in cold
temperature, etc., warm the bonding surfaces of the body
and side air dam to about 40
−
60
°
C (104
−
140
°
F) before
affixing the tape.
3. Firmly press in the side sill garnish.
AC200049
AB
PROTECTION TAPE
DOUBLE-SIDED TAPE
AC200050
AB
DOUBLE-SIDED TAPE
AC103187
AC103247
BACKING PAPER
ADHESIVE TAPE
AC
