GENERAL DESCRIPTION
FOUR-WHEEL ANTI-LOCK BRAKE SYSTEM (4ABS)
35B-5
ABS ELECTRICAL CIRCUIT DIAGRAM
AC211548
AB
15
15A
FL FR RL RR
ABS-ECU
10
15A
12
7.5A
7.5A
2
7.5A
5
15A
15
ANTI
LOCK
FUSIBLE
LINK 3 BATTERY
IGNITION
SWITCH (IG2)
IGNITION
SWITCH (IG1)
JUNCTION BLOCK
RELAY
BOX
STOPLIGHT
SWITCH
SOLENOID
VALVE POWER
SUPPLY
MOTOR
POWER
SUPPLY
STOPLIGHT
SWITCH
MONITOR
ECU
POWER
SUPPLY
ABS SENSOR
DATA LINK
CONNECTOR
COMMUNICATION
LINE
CONTROL
LINE
MOTOR
SOLENOID VALVE
HYDRAULIC UNIT
COMBINATION
METER
STOPLIGHT
FUSIBLE
LINK 1
LATERAL
G-SENSOR
LONGITUDINAL
G-SENSOR
STEERING
ANGULAR
VELOCITY
SENSOR
LATERAL
G-SENSOR
INPUT
STEERING ANGULAR
VELOCITY SENSOR
INPUT
LATERAL
G-SENSOR
INPUT
PARKING BRAKE
SWITCH MONITOR
PARKING
BRAKE
SWITCH
(FL) (FR) (RL) (RR)
